Descripción

CARACTERÍSTICAS DE HARDWARE
ProcesadorQualcomm 560MHz CPU, MIPS 74Kc
Memoria64MB DDR2 RAM,8MB Flash
Interface1 10/100Mbps Shielded Ethernet Port (LAN/POE)
1 Reset Button
Fuente de AlimentaciónPassive Power over Ethernet via LAN (+4,5pins; -7,8pins)
Voltage range: 16-27VDC
Dimensiones (W X D X H)366 x 280 x 207 mm (14.4 x 11.0 x 8.1 in.)
Dimensiones360 x 280 x 207 mm (14.4 x 11.0 x 8.1 in.) (No mount)
Ganancia de Antena23dBi
Cobertura de Antena9°(Azimuth), 7°(Elevation)
Protección15KV ESD Protection
6KV Lightning Protection
CercadoMaterial: Outdoor PC stabilized plastic
Weatherproof: IP65 water and dust proof design
CARACTERÍSTICAS INALÁMBRICAS
Estándares InalámbricosIEEE 802.11a/n
Protocolo PropietarioTDMA Mode (with Pharos MAXtream enabled)
Velocidades InalámbricasUp to 300Mbps (40MHz,Dynamic)
Up to 144.4Mbps (20MHz,Dynamic)
Up to 72.2Mbps (10MHz,Dynamic)
Up to 36.1Mbps (5MHz,Dynamic)
Frecuencia5.15~5.85GHz
Potencia de TransmisionMax. 27dBm (Adjustable power by 1dBm)
CARACTERÍSTICAS DE SOFTWARE
Configuracion De RedWAN: Static/Dynamic/PPPoE/L2TP/PPTP
LAN: Static/Dynamic/DHCP
Forwarding: ALG/UPnP/Virtual Server/Port Trigger
Security: SPI Firewall/ Ping Forbidden/DoS Protection
Access Control
Static Routing
Bandwidth Control
IP & MAC Binding
Configuraciones InalámbricasPharos MAXtream TDMA Technology
Selectable Channel Width: 5/10/20/40MHz
Auto Channel Selection
Transmit Power Control
Dynamic Frequency Selection(DFS)
WDS Enable/Disable
Security: WPA/WPA2, WPA-PSK/WPA2-PSK (AES/TKIP) Encryption,
64/128/152-bit WEP Encryption
SSID Broadcast Enable/Disable
Multi-SSID with VLAN Tagging(AP Mode only)
Distance/ACK Timeout Setting
Wireless MAC Address Filter
Wireless Advanced:
Beacon Interval/RTS Threshold/Fragmentation Threshold/DTIM Interval/AP Isolation/Short GI/Wi-Fi Multimedia
AdministraciónDiscovery and Remote Management via Pharos Control application
HTTP/HTTPS Web-based management
System log
SNMP Agent(v2c)
Ping Watch Dog
Dynamic DDNS
SSH Server
Herramientas de sistemaIndicators:Signal Strength/Noise/Transmit CCQ/CPU/Memory
Monitors: Throughput/Stations/Interfaces/ARP/Routes/WAN/DHCP
Spectrum Analyzer
Speed Test
Ping
Traceroute
Optimizaciones a Nivel de SistemaOptimized IGMP Snooping/Proxy for multicast applications
Hardware watch dog
POE ADAPTER FEATURES
Dimensions(W x D x H)85.8×43.9×29.7 mm
Interfaces1 AC Jack with Earth Ground
1 10/100Mbps Shielded Ethernet Port (Power + Data)
1 10/100Mbps Shielded Ethernet Port (Data)
BotónRemote Reset Button
Power Status LEDsGreen
Input100-240VAC, 50/60Hz
Output24VDC, 0.5A Max
+4, 5pins; -7, 8pins. (Support up to 60m Power over Ethernet)
Eficiencia>84.29%
CertificationsCE/FCC/UL/IC/GS/PSB/C-tick/SAA/S-Mark/KC-mark
OTROS
CertificacionCE, FCC, RoHS, IP65
Contenidos del PaqueteOutdoor Wireless CPE
24V 0.5A Passive PoE Adapter
Pole Mounting Straps
AC Power Cord
Installation Guide
Requisitos del SistemaMicrosoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 10, Windows 8, Windows 7, MAC OS, NetWare, UNIX or Linux.
Note: We recommend you to use one of following Web browsers for an improved user experience: Google Chrome, Safari, and Firefox. IE browsers are not recommended.
AmbienteOperating Temperature: -40℃~70℃ (-40℉~158℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~95% non-condensing

Ficha tecnica

Modelo
N4-CPE610-166318
Stock
459
Referencia
CPE610
Actualizado
2026-04-02 01:07:27
