| Operating voltage | 12/24 VDC |
| Holding force | 600-lb (272kg) |
| Current draw | 500mA@12VDC, 250mA@24VDC |
| IP Rating | IP65 |
| Connections | 18″ (457mm) Armored door cord with housing |
| Operating temperature | 14°~131° F (-10°~55° C) |
| Dimensions | Maglock: 8″x1-11/16″x1-9/16″ (203x43x40 mm) Armature Plate: 7-1/4″x1-5/8″x9/16″ (185x41x14 mm) |
| Weight | 6-lb 2-oz (2.76kg) |
