TECHNICAL DATA
GENERAL
Voltage rating
250 V AC/DC
Current rating
5 A AC/DC
Withstand voltage
1500 V AC for 1 minute
Insulation resistance
1000 MΩ min
Temperature range
– 25 °C ~ + 85 °C
Contact resistance
10 mΩ
Insulator material
Nylon 66
Internal contacts material
Phosphor Bronze / Brass
