System Specifications

RG-CS83-24GT4XS

RG-CS83-48GT4XS

RG-CS83-12GT4XS-P

RG-CS83-24GT4XS-P

RG-CS83-48GT4XS-P

Packet forwarding rate

96 Mpps

132 Mpps

78 Mpps

96 Mpps

132 Mpps

Switching capacity

128 Gbps

176 Gbps

104 Gbps

128 Gbps

176 Gbps

CPU

Dual-core CPU, each core with the clock speed of 1.0 GHz

BootROM

16 MB (storing boot software for 1+1 boot redundancy)

Flash memory

512 MB (storing boot software for 1+1 boot redundancy)

Memory

1 GB

Switch buffer

1.5 MB

MAC address table size

16,000

ARP table size

4,000

Number of IPv4 unicast routes

6,000

Number of IPv4 multicast routes

1,000

Number of IPv6 unicast routes

2,000

Number of IPv6 multicast routes

750

Number of ACEs

Ingress: 1,750

Egress: 800

Number of VSU members

4
